Socket Weld Gate Valve

Get a Price/Quote

MOQ : 5 Units

Socket Weld Gate Valve Specification

Sealing
Metal-to-Metal or PTFE

Size
1/2 inch, 3/4 inch, 1 inch, 1.5 inch, 2 inch

Structure
Gate

Connection
Socket Weld

Material
Forged Steel / Stainless Steel

Type
Socket Weld Gate Valve

Power Source
Manual

Pressure
Class 150 to Class 800

Media
Water, Oil, Gas, Steam

Working Temperature
-20C to 250C

Port Size
1/2 inch to 2 inch

Surface
Polished

Shape
Straight

Standard
ASTM/AISI/ANSI

Corrosion Resistance
Yes

Operation
Handwheel

Stem Material
Stainless Steel

Bonnet Type
Bolted

Leakage Class
Class VI

Mounting Position
Vertical / Horizontal

End Connection
Socket Welded

Testing Standard
API 598

Disc Type
Solid wedge

Application
Industrial / Plumbing / Pipeline Systems

Face to Face
ASME B16.10

Body Material Grade
SS304/SS316

Socket Weld Gate Valve Trade Information

Minimum Order Quantity
5 Units

Supply Ability
200 Units Per Month

Delivery Time
7 Days

About Socket Weld Gate Valve

Socket Weld Gate Valve is easy to install and maintain. It is made in our state of the art production site making the best use of pioneering tools and techniques. Having rugged construction, resilience, and cutting-edge design, the offered gate valve does not degrade in quality or become inferior in the long run. It is capable of standing chemical attacks, heavy loads, and rust. Socket Weld Gate Valve is easy to install and maintain. Due to its reliable performance and longevity, we are experiencing a huge demand for the gate valve in the marketplace.

Main Features :

Bolted body-bonnet design for valves up to Class 800, 1500, 2500, 4500. Valves with welded bonnet also available on request
Screwed with a seal-welded body-bonnet design for valves of Class 1500,2500, 4500.
Bellows-sealed Gate and Globe valves available in Class 800
Bolted body-bonnet joints provided with spiral-wound stainless steel gasket and graphite filler for maximum protection against leaks
Die-formed graphite inner packing rings and braided graphite end rings with Inconel wire reinforcement and corrosion inhibitor
T-head stem-disc connection of gate valve fully meets strength requirements of API 602 and API 598
Rolled ACME thread on stem for smooth operation
Tapered shoulder on the stem for back seating
Self-aligning type gland assembly with stud-and-nut tightening
Integral hard-faced body seat for globe and check valves
Spring-loaded disc on check valves suitable for no horizontal applications too
Gate and globe valves can be offered with electrical actuators
Austenitic SS forging for body and bonnet of Cryogenic valves, resulting in excellent impact strength, minimal heat loss and resistance to corrosion
Valves can be offered to NACE MR-0175 and other special NACE requirements

Versatile Applications in Industrial Systems

The Socket Weld Gate Valve excels in diverse fields such as industrial process lines, plumbing, and extensive pipeline systems. Its compatibility with various mediaincluding water, oil, gas, and steammakes it a reliable component in demanding environments. Suitable for both horizontal and vertical installations, it meets rigorous performance and safety standards in operations requiring dependable shut-off and flow management.

Robust Construction and Material Quality

Built with premium SS304 or SS316 stainless steel and forged steel options, this valve delivers superior mechanical strength and corrosion resistance. The polished finish enhances longevity, while the solid wedge disc and bolted bonnet structure ensure enduring performance. Its compliance with internationally recognized standards like ASTM, ANSI, ASME B16.10, and API 598 further guarantees its quality and reliability.

FAQs of Socket Weld Gate Valve:

Q: How does the Socket Weld Gate Valve ensure leak-tight operation?

A: The valve uses a solid wedge disc and features either metal-to-metal or PTFE sealing. It is manufactured according to strict API 598 testing standards and classified as Leakage Class VI, ensuring minimal leakage and consistent, reliable shut-off in pipeline systems.

Q: What is the primary benefit of using socket weld connections for this gate valve?

A: Socket weld connections provide a secure, leak-resistant joint, ideal for high-pressure and high-temperature industrial applications. This makes installation straightforward while maintaining robust integrity for demanding pipeline environments.

Q: When is it recommended to use this gate valve in an industrial setup?

A: Install this socket weld gate valve when dealing with applications that require frequent shut-off or regulation of water, oil, gas, or steam. Its durable construction and broad compatibility with working temperatures and pressures make it suitable for critical industrial pipelines.

Q: Where can the Socket Weld Gate Valve be mounted within a system?

A: The valve is designed for versatility and can be mounted in either a vertical or horizontal orientation, accommodating various pipeline layouts and operational needs across plumbing and industrial sectors.

Q: What steps should be followed during installation of this gate valve?

A: During installation, ensure the pipeline and valve ends are clean and properly aligned. Use socket welding techniques for a solid connection, avoiding any misalignment. Verify that the valve is fitted according to ASME B16.10 face-to-face dimensions and check for leaks as per API 598 after installation.

Q: How does the construction material affect the valves performance?

A: The use of SS304/SS316 stainless steel or forged steel enhances resistance to corrosion and mechanical stress, making the valve suitable for a range of aggressive and high-pressure media. This assures a longer operational lifespan with less maintenance.
