API 607 Ball Valve

Get a Price/Quote

MOQ : 5 Units

API 607 Ball Valve Specification

Connection
Flanged / Screwed / Welded

Structure
Floating Ball / Trunnion Mounted

Pressure
Class 150 to 600 (PN 16 - PN 100)

Caliber
Full Bore / Reduced Bore

Channels
2-Way / 3-Way

Material
Stainless Steel / Carbon Steel / Cast Steel

Power
Manual / Pneumatic / Electric

Media
Gas, Oil, Water, Steam, Chemicals

Temperature of Media
-29C to 425C

Port Size
1/2 to 12

Flange
ANSI B16.5, Class 150/300/600

Finish
Epoxy Coated / Polished

Application
Petrochemical, Oil & Gas, Power Plant, Water Treatment

Top Flange Availability
As Per ISO 5211

Sealing
Soft Seated / Metal Seated

Design Standard
API 607 / API 6D / BS 5351

Operated Type
Lever / Gear Box / Actuator

Handle Material
Stainless Steel / Carbon Steel

Body Style
One Piece / Two Piece / Three Piece

Seat Material
PTFE / RPTFE / Metal

Testing Standard
API 598

Locking Device
Optional

Anti-Static Device
Provided

Blow-Out Proof Stem
Available

ISO Mounting Pad
Yes

End Connection
RF / RTJ / BW / SW

Fire Safe Certification
Certified to API 607 (Fire Safe)

Operation
Quarter Turn

API 607 Ball Valve Trade Information

Minimum Order Quantity
5 Units

Supply Ability
200 Units Per Month

Delivery Time
7 Days

About API 607 Ball Valve

API 607 Ball Valve

Size	2" to 56" (50 mm to 1400 mm)
ASME Class	Class 150 to 2500
Design Standard	API 6D

Main Feature

· Trunnion-mounted Ball Valve design complies to API 6D

· Wide portfolio of Side-entry and Top-entry designs

· Fugitive emissions

· Soft and Metal seated valves complies to ISO 15848-1, Class AH and BH

· Fire safe design - to API 607 and API 6FACE Marking

· Meets requirements of Pressure Equipment Directive 2014/68/EU,

· Pneumatic shell test conducted at 1.1 times rated pressure to check shell integrity, when required · Double block and bleed (DBB) feature

· Valves are designed and tested for automatic cavity relief

· Anti-blowout stem design

· Coil springs used for consistent seat loading and lower operating torque

· Lip seals provided for low temperature services

· Primary O ring and Secondary graphite (in 3 stage stem, thrust washer is primary)

· Wide portfolio of Side-entry and Top-entry designs

· Options: Buried service, Cryogenic

· Offered with Electric, Pneumatic and Hydraulic Actuators

· In-house Tests Capabilities

Fire Safe Certified Reliability

The API 607 Ball Valve is certified to API 607 standards, ensuring enhanced fire safety in critical industrial applications. Its blow-out proof stem and anti-static device provide additional layers of operational security, making it ideal for handling volatile media in petrochemical and oil & gas sectors. This assures operator safety and protects infrastructure even under extreme conditions.

Versatile Operation and Connection Options

This valve offers flexibility with manual, pneumatic, or electric actuation, available as lever, gear box, or actuator operated types. End connections include RF, RTJ, BW, SW, and flange designs conforming to ANSI B16.5 standards. The wide selection allows seamless integration with existing piping systems, making it easy for engineers to choose the right configuration for their application.

Durability and Customization

Constructed from premium stainless steel, carbon steel, or cast steel, this ball valve is engineered for longevity and resistance to corrosion. Its epoxy coating or polished finish further enhances durability. Options for seat and handle materials, locking devices, and top flange mounting as per ISO 5211 ensure it can be tailored precisely to customer requirements without compromising performance.

FAQ's of API 607 Ball Valve:

Q: How does the API 607 Ball Valve ensure fire safety in industrial applications?

A: The valve is certified to API 607, which mandates strict fire-safe design and testing procedures. It incorporates features like an anti-static device, blow-out proof stem, and metal or soft seated sealing, safeguarding against leakage and failure during fire incidents in hazardous environments.

Q: What types of media can the API 607 Ball Valve handle effectively?

A: This valve is suitable for a variety of media including gas, oil, water, steam, and chemicals. Its robust construction and versatile seat materials ensure reliable sealing and operation across a wide temperature range from -29C to 425C.

Q: When should I consider using a metal seated API 607 Ball Valve instead of a soft seated one?

A: Metal seated valves are recommended for applications involving abrasive media, high temperatures, or severe service conditions, whereas soft seated options (PTFE/RPTFE) are ideal for general-purpose or lower temperature media where tight sealing is required.

Q: Where can the API 607 Ball Valve be installed within my facility?

A: Thanks to its variety of connection types-flanged, screwed, or welded-the valve is suitable for integration into pipelines within petrochemical plants, oil & gas facilities, power stations, or water treatment installations, adapting to both high and low pressure zones.

Q: What is the process for selecting the suitable API 607 Ball Valve configuration?

A: Identify the media, pressure, and temperature requirements, then choose appropriate seat, body, and handle materials. Select the operating type (manual, pneumatic, electric), connection style, and bore size based on system needs and ensure compliance with relevant standards like ISO 5211 and ANSI B16.5.

Q: How is the API 607 Ball Valve beneficial to distributors and manufacturers in India?

A: Its wide range of customizable options, strict adherence to global standards, and robust fire-safe certification offer assurance of quality and reliability, enabling distributors, exporters, and manufacturers to meet diverse client specifications and expand market presence.
