A217 WC6 Cast Alloy Steel Piston Valve

Get a Price/Quote

MOQ : 5 Units

A217 WC6 Cast Alloy Steel Piston Valve Specification

Structure
Bolted Bonnet, Piston Disc Type

Material
A217 WC6 Cast Alloy Steel

Power
Manual

Pressure
Class 150 to 2500

Media
Gas, Water, Oil, Steam

Working Temperature
Up to 593C (1100F)

Port Size
1/2 to 12 (DN15 to DN300)

Surface
Shot Blasted, Painted

Shape
Straight Pattern

Application
Steam, Oil, Gas, High Temperature & Pressure Service

Seat Test Pressure
1.1 times the working pressure

Standards
API 600, ASME B16.34, DIN

End Connection
Flanged, Butt Weld, Socket Weld

Operation
Handwheel

Body Test Pressure
1.5 times the working pressure

A217 WC6 Cast Alloy Steel Piston Valve Trade Information

Minimum Order Quantity
5 Units

Supply Ability
200 Units Per Month

Delivery Time
7 Days

About A217 WC6 Cast Alloy Steel Piston Valve

A217 WC6 Cast Alloy Steel Piston Valve is widely acclaimed among our customers owing to its superior design and quality. The piston valve has got ruggedness and high build quality. It is made out of the first-rate alloyed metal that is resistant to chemical attacks, heavy pressure, abrasion, and other degrading factors. For this reason, the tool does not degrade in quality or performance for years. It is typically used to control the pressure and flow rate of fluids and maintains unidirectional flow. A217 WC6 Cast Alloy Steel Piston Valve can be purchased from us at a cost-effective price.

Full port forged steel isolation valves with a maximum operating pressure of 1973 psig/136 Barg and a maximum operating temperature of 800oF/427oC. The burnished piston and metal reinforced graphite rings provide leak-proof shut off and allow Piston Valves to be operated at higher temperatures, while also extending operating life.

Piston Valves are available in Socket Weld, BSPT, and NPT end connections. Flanged ends can be supplied upon request. Piston Valves are ideal for saturated and superheated steam, and hot water applications.

Piston Valves Feature :

Leak-proof isolation
Sizes from 1/2"/15mm to 1-1/2"/40mm
Choice of socket weld or threaded connections
Compatible with ASME
Resistant to cavitation
All sealing valve components may be easily replaced in-line
Long-term operation. Piston valve design ensures actuation even after many years without operation
Fire-proof performance

Design Standards :

ASME (B16.34, B16.5)
Inspection and testing (API 598)
Leak test (ANSI/FCI 70-2 )
Fire test (API SPEC 6FA : 1999

Design features of Piston Valves :

Materials of Construction

Body and Bonnet ASTM A105N / A350 LF2 Forged Steel
Spindle SS T304
Ring Valve SS T3016 + Graphite
Piston SS 17-4 PH
Spacer CA 40
Belleville Washer ASTM A231
Name Plate SS 304

Versatile Connection Options

Choose from flanged, butt weld, or socket weld end connections to suit your specific pipeline requirements, ensuring reliable integration even in challenging installation environments. These standardized connections facilitate straightforward replacement and maintenance, backed by global compatibility and compliance.

High-Temperature & Pressure Service

The valve's robust A217 WC6 cast alloy steel construction and piston disc design are built for demanding steam, oil, and gas applications. Rated for operations up to 593C and high-pressure classes, this valve maintains sealing integrity and operational safety in critical industrial processes.

Precision Standards & Quality Assurance

Manufactured in accordance with API 600, ASME B16.34, and DIN norms, each valve undergoes body and seat test pressures exceeding working conditions (1.5x and 1.1x, respectively), ensuring leak-free service. Its bolted bonnet structure facilitates maintenance, contributing to lower lifecycle costs.

FAQ's of A217 WC6 Cast Alloy Steel Piston Valve:

Q: How is the A217 WC6 Cast Alloy Steel Piston Valve typically operated?

A: This piston valve is manually operated with a handwheel, allowing precise and reliable control over media flow in steam, gas, or oil pipelines.

Q: What standards does the valve comply with to guarantee safety and performance?

A: The valve conforms to API 600, ASME B16.34, and DIN standards, which ensure consistent quality, safety, and reliable performance in industrial applications.

Q: When should this valve be used in industrial settings?

A: It is ideal for high-temperature and high-pressure conditions, up to 593C (1100F), especially in steam, oil, and gas services that require durable valve solutions.

Q: Where can this valve be installed, considering its end connection options?

A: The valve's flanged, butt weld, or socket weld ends make it suitable for a variety of pipeline systems, facilitating installation in diverse industrial environments.

Q: What is the process for pressure testing these valves before deployment?

A: Each valve is subjected to a body test at 1.5 times the working pressure and a seat test at 1.1 times the working pressure, ensuring safety and leak-proof performance before installation.

Q: What benefits does the piston disc type valve offer for media control?

A: The piston disc design provides enhanced sealing, minimizes leakage, and offers dependable operation under fluctuating pressures and temperatures, resulting in improved process stability.

Q: How does the valve's construction contribute to its longevity and maintenance?

A: Its bolted bonnet structure allows easy access for inspection and maintenance, while the shot blasted and painted finish offers greater resistance to corrosion, extending service life.
