A105 Forged Carbon Steel Gate Valve

Get a Price/Quote

MOQ : 5 Units

A105 Forged Carbon Steel Gate Valve Specification

Structure
Bolted Bonnet

Sealing
Soft or Metal Seated

Size
DN15 to DN50

Connection
Socket Weld (SW) / Threaded (NPT/BSP) / Flanged

Material
A105 Forged Carbon Steel

Type
Forged Gate Valve

Power Source
Manual

Pressure
800LB, 1500LB, 2500LB

Media
Water, Oil, Gas, Steam

Working Temperature
-29C to 425C

Port Size
1/2 to 2

Surface
Black Painted or Anti-rust Oil

Shape
Straight Pattern

Standard
API 602, ASME B16.34

Face to Face
ASME B16.10

Color
Black

Stem Type
Rising / Non-rising Stem

End Connection
SW / NPT / Flanged

Body Cover Joint
Bolted / Welded Bonnet

Application
Industrial pipelines, Oil & Gas, Petrochemical, Power Plants

Packing
Graphite / PTFE

Test Standard
API 598

Operation
Hand Wheel

Trim
F6a / F304 / F316

Body Material
ASTM A105 Forged Steel

Wedge Type
Solid Wedge

A105 Forged Carbon Steel Gate Valve Trade Information

Minimum Order Quantity
5 Units

Supply Ability
200 Units Per Month

Delivery Time
7 Days

About A105 Forged Carbon Steel Gate Valve

A105 Forged Carbon Steel Gate Valve

Main Features :

Bolted body-bonnet design for valves up to Class 800, 1500, 2500, 4500. Valves with welded bonnet also available on request
Screwed with a seal-welded body-bonnet design for valves of Class 1500,2500, 4500.
Bellows-sealed Gate and Globe valves available in Class 800
Bolted body-bonnet joints provided with spiral-wound stainless steel gasket and graphite filler for maximum protection against leaks
Die-formed graphite inner packing rings and braided graphite end rings with Inconel wire reinforcement and corrosion inhibitor
T-head stem-disc connection of gate valve fully meets strength requirements of API 602 and API 598
Rolled ACME thread on stem for smooth operation
Tapered shoulder on the stem for back seating
Self-aligning type gland assembly with stud-and-nut tightening
Integral hard-faced body seat for globe and check valves
Spring-loaded disc on check valves suitable for no horizontal applications too
Gate and globe valves can be offered with electrical actuators
Austenitic SS forging for body and bonnet of Cryogenic valves, resulting in excellent impact strength, minimal heat loss and resistance to corrosion
Valves can be offered to NACE MR-0175 and other special NACE requirements

Specification

End Connection Type	Screwed
Size	2.5 - 7.5"
Material	Carbon Steel
Brand	SQK
Automation Grade	Manual
Media	Water, Chemical, Oil etc
Usage/Application	Petroleum refineries, Chemical plants, Power generating plants etc

Industrial-grade Reliability & Performance

The A105 Forged Carbon Steel Gate Valve is engineered for consistent performance under demanding conditions. Its forged construction ensures durability, while compliance with international standards like API 602 and ASME B16.34 guarantees robust shut-off capabilities. Offering a choice of sealing and trim materials, it is versatile for use in diverse media - such as water, oil, gas, and steam - across a range of industries, delivering secure and leak-tight operations.

Versatile Installation & Operation

With multiple end connections including socket weld, threaded (NPT/BSP), and flanged, this valve simplifies integration into various piping systems. Its hand wheel operation, available in both rising and non-rising stem configurations, enables precise manual control. The valve's straightforward maintenance and multiple body cover joint options (bolted or welded bonnet) further enhance usability for installers and operators alike.

FAQ's of A105 Forged Carbon Steel Gate Valve:

Q: How is the A105 Forged Carbon Steel Gate Valve typically installed in industrial pipelines?

A: This gate valve can be installed using socket weld (SW), threaded (NPT/BSP), or flanged end connections, allowing compatibility with a wide range of pipeline configurations in industrial environments. Installation should comply with industry standards for alignment and torque to ensure optimal sealing and performance.

Q: What are the primary benefits of using this forged gate valve in oil & gas or power plant applications?

A: The A105 forged gate valve provides exceptional durability, reliable shut-off, and high resistance to pressure and temperature fluctuations, making it ideal for the stringent requirements of oil & gas, petrochemical, and power generation sectors.

Q: When should a solid wedge type gate valve be used over other types?

A: A solid wedge gate valve, such as this model, is best suited for applications involving high pressure and temperature, as its robust design provides consistent sealing and less susceptibility to warping or misalignment due to thermal variations.

Q: Where can this valve be sourced for large-scale projects?

A: The A105 Forged Carbon Steel Gate Valve is available from leading distributors, exporters, manufacturers, suppliers, and traders in India, ensuring local and international procurement support for large projects.

Q: What process ensures the valve's performance under pressure and temperature limits?

A: Each valve undergoes rigorous leak and pressure testing as per API 598 standards, validating its integrity and operational reliability across a working temperature range of -29C to 425C and pressure ratings up to 2500LB.

Q: How should this gate valve be maintained for optimal service life?

A: Maintenance involves periodic inspection of packing (graphite/PTFE), stem lubrication for manual operation, and checking the bonnet joint (bolted or welded) for leaks, ensuring sustained performance and longevity.
