Buttweld End Globe Valve

About Buttweld End Globe Valve

Buttweld End  Globe Valve

Offered Buttweld End Globe Valve is reckoned for its ergonomic look and reasonable price. It is mainly used as essential part of gas transferring pipelines. Its nominal pressure is 4.0Mpa and its operating temperature ranges between-196 degree C to 85 degree C. Provided Buttweld End Globe Valve is appreciated for its long working life, high strength, reasonable price, quick fixing method and global standard. We offer this valve at reasonable price. Its standard has been tested on the basis of its design precision, longevity, durability and surface finish.



The BS 1873 Globe Valves is exceptionally sturdy, rugged and durable, with a reputation for quality, integrity and long service.

They are designed for tight sealing and ease of operation. The valves are available flanged & butt-weld ends in pressure rating from ASME Class 150 to Class 2500, and in a variety of materials of construction.

 Globe Valves feature a ball-type disc, outside screw-and-yoke and bolted-bonnet construction. They conform to BS 1873 and also meet the general requirements of API 600, including shell wall thickness and stuffing box dimensions.



Main features

         Bolted body-bonnet design,seal welded & Valves with pressure seal bonnet

         Bellows-sealed Globe valves available

         Bolted body-bonnet joints provided with spiral-wound stainless steel gasket and graphite filler for maximum protection against leaks

         Die-formed graphite inner packing rings and braided graphite end rings with Inconel wire reinforcement and corrosion inhibitor

         Rolled ACME thread on stem for smooth operation

         Tapered shoulder on the stem for back seating

         Self-aligning type gland assembly with stud-and-nut tightening

         Integral hard-faced body seat for globe and check valves

         Spring-loaded disc on check valves suitable for no horizontal applications too

         Gate and globe valves can be offered with electrical actuators

         Austenitic SS forging for body and bonnet of Cryogenic valves, resulting in excellent impact strength, minimal heat loss and resistance to corrosion

         Valves can be offered to NACE MR-0175 and other special NACE requirements



Cast steel ASME B16.34 T Type & Y Type Globe Valves Pressure Seal Bonnet design

The ASME B16.34 series of T Type & Y Type Globe Valves features a pressure seal bonnet design for high pressure services. These valves are extensively used in high pressure and high temperature steam, oil, gas, chemical and water applications in thermal power plants, fertiliser plants, petrochemical plants and refineries. These valves are available in butt weld ends in pressure ratings of Classes 900, 1500 and 2500, and come in carbon steel and alloy steel construction.



Cast Steel Cryogenic Globe Valves



Specially-adopted, extended-bonnet globe valves provide the right solution for such low-temperature and cryogenic services. We offer a range of globe valves (as well as check valves) for low temperature and cryogenic services, used in processing, storage and transportation of liquefied gases such as Ethylene, LPG,LNG, Hydrogen, Helium, Oxygen, Nitrogen and Argon. Low temperature services of up to -460 C are covered by low-temperature carbon steels like LCB and LCC materials. Cryogenic Globe Valves are available in ASME Classes 150 to 1500. Extended Bonnet Optional extended bonnet with vapour column length according to BS 6364 and / or customer specifications will be provided

Robust Construction and Quality Assurance

Manufactured with a bolted bonnet and strictly tested according to API 598 standards, these globe valves assure leak-tight performance and safety. The use of premium materials like ASTM A216 WCB, CF8/CF8M stainless steel, and alloy options guarantees corrosion resistance and longevity even in high-pressure and high-temperature operations.


Versatile Industrial Application

Our globe valves are designed for seamless use across a variety of industrial sectors, including oil, gas, steam, and water applications. With buttweld ends compatible with Sch. 40/80/160 pipe specifications and face-to-face dimensions per ASME B16.10, their integration into existing pipeline systems is simple and reliable.


Efficient Operation and Maintenance

Thanks to the rising stem mechanism and precision-lapped surfaces, these valves boast low operating torque for manual control. Options for integral or renewable seat rings and easy access for maintenance help reduce downtime while promoting operational efficiency for process engineers and plant operators.
